Leather UV Digital Inkjet Printer
ZFPM ONEPASS X5PLUS

Leather UV Digital Inkjet Printer Upgraded from the standard X5 industrial UV inkjet printer and optimized exclusively for leather sample making work-flows. Adopting mature One Pass high-speed printing system, it accommodates genuine leather, PU synthetic leather, micro-fiber leather, shoe upper cut-pieces, handbag leather blanks, leather hangtags and decorative leather patches. Precise colour restoration delivers high-definition prototype samples. UVsolidified prints feature outstanding abrasion resistance for longterm sample archive. Optional sensor controlled partition groove belt receivingtable, automatic feeder and servo stacker constitute an automated sampling assembly line, satisfying high frequency multi pattern sampling requirements of leather pattern making factories.

获取报价

Detailed Product Specifications：

Product Features:

1. Inductive Slot Belt Collecting Platform

Equipped with infrared photoelectric sensor. Automatically starts/stops conveying after detecting UV cured leather, cutting idle wear. Partition groove belt design transports leather sheets separately, ideal for shoe cuts and luggage leather. Supports sensor trigger & constant speed modes, speed synchronizable with main printer to avoid leather stretching. Movable aluminium frame, expandable with auto feeder and servo stacking system.

2.  Broad Material Compatibility

Works on lunch boxes, PVC, glass, metal, carbon fibre and other flat substrates for multi industry printing.

3. Intelligent & Reliable Protection

Dual print head anti-collision protection, built in static elimination; optional plasma corona treatment for stable, safe operation.

4.  High-Quality Finish

Achieves high gloss, matte and partial varnish effects, replacing screen printing and hot stamping to upgrade product appearance.

5. Smart Ink Supply

Cassette large volume ink tank, low-ink alarm and auto-filtration, minimising manual work and ink waste.

6.  Three Level Efficient Modes

4/6/8 PASS options, output: 28 / 21 / 14 m²/h, balancing speed and printing precision.

7. Excellent Curved Surface Printing

Prints complex curved automotive interior parts, breaking traditional flat printing restrictions.


Scope of Application:

The X5PLUS Leather UV Digital Inkjet Printer is custom built for leather sample workshops. It prints sharp patterns on shoe upper prototypes, leather hang tags, handbag material samples and leather ornaments. Boasting proven OnePass high-speed printing, it produces samples with accurate colours. UV hardened prints are wear resistant and long lasting. Optional sensor controlled grooved belt receiver, auto feeder and servo stacker support automated workflow for frequent multi style sampling.
